Tokyo Primo JR 4x4 TLR


Tokyo Primo JR 4x4 TLR

$165.00

Condition: Very good.

Tokyo Primo JR 4x4 TLR Camera Specifications (Using 127 film)

Film Format:

  • Film Type: 127 roll film

  • Image Format: 4x4 cm (16 exposures per roll of 127 film)

Lens System:

  • Taking Lens: 75mm f/3.5 (fixed lens, generally uncoated or single-coated)

  • Viewing Lens: 75mm f/3.5 (same as the taking lens, used for composing the image)

Shutter:

  • Shutter Type: Mechanical leaf shutter (no electronics)

  • Shutter Speeds: 1/25s to 1/500s + Bulb mode

  • Flash Sync: X-sync (for flash synchronization)

Aperture:

  • Aperture Range: f/3.5 to f/22

Focusing:

  • Focusing Mechanism: Manual focus using a focus knob

  • Focusing Range: From 1 meter (3.3 feet) to infinity

  • Focusing Aid: Ground glass with a central split-image or microprism collar for accurate focusing

Viewfinder:

  • Type: Waist-level finder (viewing is done from above, looking down into the camera)

  • Magnification: Approximately 1x (for life-size composition)

  • Focusing Aid: Ground glass screen with split-image or microprism for focusing accuracy

Film Transport:

  • Film Advance: Manual crank

  • Film Rewind: Manual rewind knob

  • Number of Exposures: 16 exposures per roll of 127 film

Dimensions and Weight:

  • Dimensions: Approximately 11.5 cm x 11.5 cm x 10 cm (4.5 in x 4.5 in x 4 in)

  • Weight: Approximately 600-700 grams (1.3-1.5 lbs)

Other Features:

  • Build Quality: Typically made from a combination of metal and plastic, lightweight and compact for a TLR.

  • Tripod Socket: 1/4" tripod thread for mounting on a tripod

  • Shutter Release: Mechanical button release or optional cable release

Summary of the Tokyo Primo JR 4x4 TLR:

  • The Tokyo Primo JR 4x4 TLR uses 127 film, which is significantly smaller than 120 film, yielding 4x4 cm square images.

  • This camera is a compact TLR designed for people who want to experiment with the twin-lens reflex system but prefer a smaller and more portable format.

  • With 16 exposures on a roll of 127 film, it's a great choice for vintage film enthusiasts.

  • It features manual controls for focus, aperture, and shutter speed, offering a classic, hands-on shooting experience.
